This document contains reliability data on both commercial and military electronic components for use in reliability analyses. It contains failure rate data on integrated circuits, discrete semiconductors (diodes, transistors, optoelectronic devices), resistors, capacitors, and inductors/transformers, all of which were obtained from the field usage of electronic components. At 2,716 pages, the format of this document is the same as RIAC’s popular NPRD document which contains reliability data on nonelectronic component and electronic assembly types.
Data includes part descriptions, quality level, application environments, point estimates of failure rate, data sources, number of failures, total operating hours, miles, or cycles, and detailed part characteristics.
EPRD is available in two formats:
1) Hardcopy Version
The hardcopy version is comprised of the following sections:
1 – Introduction
2 – Part Summaries
3 – Part Details
4 – Data Sources
5 – Part/MIL Number Index
6 – NSN Index w/FSC
7 – NSN Index w/o FSC
8 – Part Description Index
* NOTE: The Hardcopy Version does not include any software for searching.
2) Electronic Database Software
The Automated Databook version of this publication is a Windows compatible database driven software tool that includes query capabilities for rapid data retrieval.
The electronic database software tool is available on CD-ROM or by download.
Licensing Information and Available Formats
Individual License: (Download, CD-ROM, or Text Reader)
Individual License (for installation on a single computer for use by one individual at any time).
Site License: (Download, CD-ROM, or Text Reader)
Site License (for use within a 50-mile radius of the primary point of use).
Corporate License: (Download, CD-ROM, or Text Reader)
Corporate License (for global use, limited to the employees of a single agency or corporation).–>
*Available in Hardcopy, Download, CD-ROM, Text Reader, and Subscriptions.
NOTE: The Automated Text Reader provides access to all the information contained in the individual sections of the EPRD hard copy product. Within each individual section of EPRD, the tool provides basic search and browsing capabilities that allow for locating the information of interest.
*NOTE: The CD-ROM, download and Automated Text Reader versions are not PDF versions of this hardcopy document. The CD, Download and Automated Text Reader formats operate in Windows XP, Vista, 7, 8, 8.1 and 10 environment. The subscription version will work on any operating system including Apple Mac machines.
